CONDUCTIVITY METER

Product Description

Since 2012, we have been instrumental in putting forward the finest grade Conductivity Meter for our valued clients. The offered meter is manufactured by a team of skilled professionals using supreme quality components with the aid of innovative techniques. Widely used in hydroponics, aquaculture and freshwater systems, this meter is utilized to monitor the amount of nutrients, salts or impurities in the water. Apart from this, the provided Conductivity Meter is available at competitive prices for patrons.

Features:

• Easy to operate
• Consume low power
• High tensile strength
• Accurate determination

FEATURES:

LMCM conductivity meters includes measurement of conductivity temperature in liquids

AUTOMATIC CALIBRATION The meter is capable of calibrating up to 5 points using standard solution. From Setup Menu, choose CAL (Calibration) and press key to set known conductivity value, immerse conductivity electrode into calibration solution, press ENTER key and meter is automatically calibrated

CONDUCTIVITY AUTO-RANGING

LMCM Series have auto-range function for measuring conductivity. Upon immersing conductivity sensor into sample solution, the screen immediately displays the value in appropriate measurement range for accuracy.

AUTOMATIC TEMPERATURE COMPENSATION Using the supplied temperature probe, the temperature value is displayed on the screen. The meter automatically compensates for optimum accuracy under variable temperature conditions

ADJUSTABLE TEMPERATURE COEFFICIENT AND CELL CONSTANT Various Ions may have different temperature coefficients. The meters can set the temperature coefficient between 0 and 3.9% in degrees centigrade for optimum accuracy, set three cell constants(O.1,1 and 10) for measuring requirements

SPECIFICATION:

Conductivity Range :                          0.00 to (1.999,19.99,199.9,1999 μs, 19.99,) 200.0 ms

Conductivity Accuracy :         ±1% F.S

Temperature Range :               0 to100 °C

Temperature Accuracy :          ±1° C

Temperature Coefficient :        0 to 3.9% per °C

Calibration Points :                  1 point per range

Calibration Solution :              10 to 17μS, 100 to 170μs, 1000 to

                                                     1700μS, 10 to 17 ms

Cell Constant :                                    0.1, 1.0, 10 adjustable

Temperature Compensation : 0 to 50°C, Manual or Automatic

METER INCLUDES :

Conductivity cell ( K=1 ) , Temperature Probe (ForLMCM-20), Electrode Holder Arm, 9VAC Adaptor & Instruction Manual
