Melting Point Apparatus
Product Details:
X
Melting Point Apparatus Price And Quantity
- 1 Unit
Melting Point Apparatus Trade Information
- Telegraphic Transfer (T/T) Cheque
- 10 Unit Per Week
- 1 Week
- Asia
- All India
Product Description
Backed with a team of experienced professionals, we have emerged as a successful manufacturer and trader of scientific instruments like Advance Melting Point Apparatus. This specially developed Advance Melting Point Apparatus can determine and register melting and boiling point of three samples at the same time. It is designed with high resolution camera f or providing sample image on its high resolution monitor, self explanatory keyboard for controlling the speed of its stirrer, advanced memory function for recording the m names of 99 products along with their melting point, graphic LCD display screen with real time temperature graph, 0.5 C per minute / 1 C per minute programmable ramp rate, validation program and password protection system.
Other Details:
- Designed to measure and record the melting point of 3 samples simultaneously.
- Melting point apparatus is designed for accurate measurement of melting and boiling point of samples.
- Equipped with high resolution camera for capturing sample images being displayed on high resolution monitor; helps user determine sample melting point accurately.
- This apparatus can be used to determine the melting point of three samples at a time, while boiling point of one sample can be determined at a time.
- The self-explanatory tactile keyboard enables the operator to adjust the speed of the stirrer and select a particular test according to the product name
- Facilitated to select melting point or boiling point test type.
- Memory provision for storage of 99 product names with their expected melting point.
- Memory provision for storage of 25 product names with their expected boiling point.
- Accessorized with a graphic LCD screen displaying simple instructions for operation of the apparatus and real time Time v/s Temperature graph.
- The operator needs to input a password before starting a test.
- Provision for unknown/new product evaluation.
- Validation program for standard samples.
- 8 operator names can be stored with their corresponding passwords.
- Memory to store approximately 150 test records.
- Automatic stirrer speed controller logic.
- User programmable ramp rates (0.5 C per minute / 1 C per minute).
- PS-2/PC keyboard and DOT MATRIX printer interface.
- Data storage for operator names, product details and test data.
- On line printing facility available.
- Off line printing facility features selective printing as per date and product.
- Validation program for standard samples like Vanillin, Acetanilide and Caffeine is incorporated.
- Facility to print test reports with user's company name and instrument number.
- Password protection at different level.
Specifications:
- Temperature range: Room temperature +2 oC - 300 oC.
- Heating Media: Silicon Oil.
- Accuracy: Better than 0.5 oC.
- Temperature resolution: 0.1 oC.
- Heating rate: 1 oC/minute or 0.5 oC/minute (Starts from set temperature - 10 oC).
- No of capillary tubes: 3 for Melting Point/ 1 for Boiling Point.
- Temperature sensor: Pt - 100.
- Heater: Immersion Type.
- Capillary: Length -75 mm; Diameter: 1.4 1.6 mm.
- Display: 240 x 128 Graphic LCD.
- Input: Tactile Keyboard + PS - 2/PC keyboard.
- Printer: Parallel Interface for 80 Columns Dot Matrix Printer.
- Dimension (W x L x H): 38 x 41 x 41 cm.
- Weight: 15 Kg.
- Power Supply: 230V, 50Hz, 500 W.
- Optional special software for transferring data to local PC.
