Tablet Disintegration Tester

Product Description

We are acclaimed as one of the most versatile enterprises in this domain, engaged in providing the best grade Tablet Disintegration Tester. This tester is manufactured under the strict guidance of ingenious professionals by utilizing premium quality electronic components. The offered tester is extensively used in pharmaceutical industry and laboratories for testing the disintegration of tablets, capsules and solid dosage forms. Moreover, this Tablet Disintegration Tester can be bought from us at industry leading prices.

Features:

• Easy installation
• Accurate measure
• High performance
• Safe to use

Tablet Disintegration Tester

• PROLIFIC INSTRUMENTS IS AUTHORISED DEALER OF VEEGO INSTRUMENTS FOR THE SELLING, SERVICING & PROMOTING THEIR ENTIRE RANGE OF PRODUCTS.
• VTD-DV  IS A DOUBLE BASKET TABLET DISINTEGRATION TESTER, EQUIPPED WITH HIGH QUALITY MATERIAL & IMPROVED RECENT TECHNOLOGY IN ITS CLASS OF PRODUCT.
• TABLET DISINTEGRATION TEST APPARATUS,
• Model: VTD – DV
• MAKE : VEEGO

• Number of beakers: 2 (1000 ml Glass Beakers).
• Number of baskets: 2 (Each containing 6 glass tubes and 6 guided discs, designed as per USP, IP and BP standards).
• Number of cycles: 30 cycles/min.
• Stroke length: 55 ± 2 mm.
• Power supply: 230V, 50Hz, 1 KW max.
• Timer maximum interval setting: 4 Hours.
• Temperature range: Room Temperature to 45ºC.
• Temperature resolution: ± 0.2 ºC.
• Dimensions (L x W x H): 390 x 360 x 570 mm
• Weight: 15 Kg.
• Informative 128 x 64, blue graphic LCD display.
• Input: Tactile Keypad + PS-2/PC Keyboard.
• Memory to store 25 tests method parameters like disintegration time, temperature, alarm time and print interval.
• Compatible with DOT MATRIX printer.

• Micro controller based circuitry to precisely control, indicate and program temperature of water bath and beaker individually.
• PAUSE' facility: This facility permits chemist to check disintegration state of the tablets intermittently and continue test without disturbing the test parameters.
• Equipped with maintenance free single stepper motor.
• All parameters like- Set Test Time, Actual Test Time, Temperature, Heater's `ON/OFF' state etc, are indicated on graphic LCD display screen.
• Protection for over temperature for Heater through software and hardware.
• Software as well as hardware protection for over temperature of heater.
• Facility to measure stroke length while test is on.
• Beaker temperature of both baskets displayed individually.
• Test reports print all the detailed test parameters such as Temperature, Batch No, and Product ID etc. with ON-LINE or OFF-LINE printing facility.
• Facility to print company’s name on test report.
• Optically isolated electronic heater driver.
• Password protection at different level.
• Password protection at different level.
• Non volatile memory.
• On line / off line print facility.
• Date and product selection in off line printing.
• Power failure indication program is incorporated.
• IQ, OQ documents will be provided with the instrument..
• Validation of cycles / Min. with On/Off line printing facility.
• Facility to measure stroke length while test is `ON’.
